Car tire sensor, as an important part of modern automobile safety system, its technical principle and structure are worth our in-depth understanding. This article will introduce the basic structure of the car tire sensor in detail, including the sensor, wireless transmitter and power supply part, and in-depth explain its working principle, especially how the varistor converts the tire pressure into an electrical signal and transmits it wirelessly to the vehicle receiver.

Car tire sensor is mainly composed of three parts: Sensor, wireless transmitter and power supply. The sensor is the core component that senses changes in air pressure inside the tire. It usually uses a varistor as a key component, and the resistance value of this resistor will change with the change of pressure, thereby converting the physical quantity of tire pressure into an electrical signal. The wireless transmitter is responsible for sending the electrical signal generated by the sensor wirelessly so that the vehicle receiver can pick up the information. The power supply part provides the necessary working electricity for the car tire sensor to ensure that it can work continuously and stably.

In terms of working principle, when the air pressure in the tire changes, the resistance value of the varistor will also change. This change is converted into an electrical signal that is amplified and processed through the internal circuitry of the car tire sensor. The processed signal is picked up by a wireless transmitter and sent out in the form of radio waves. After receiving these signals, the vehicle receiver decodes and processes them to obtain real-time data on tire pressure. If the air pressure falls below or above the preset safety range, the system will issue a warning to remind the driver to take timely measures.

It is worth mentioning that the working process of car tire sensors is a highly integrated and automated process. From changes in air pressure to the conversion of electrical signals to wireless transmission and reception, every link has been carefully designed and optimized. This not only ensures the accuracy and real-time of the data, but also greatly improves the safety performance of the car.

In addition, car tire sensors also have high reliability and durability. Its internal circuit adopts advanced protection design, which can maintain stable performance in harsh working environment. At the same time, the sensor housing is also made of high-strength, corrosion-resistant materials, which can effectively resist external impact and corrosion.

To sum up, the car tire sensor with its unique technical principle and exquisite structure design, plays a pivotal role in the modern automobile safety system. It can not only monitor the change of tire pressure in real time, but also issue a warning in time when the pressure is abnormal, so as to effectively prevent traffic accidents caused by tire pressure problems. With the continuous development of automobile technology, we have reason to believe that car tire sensors will play a more important role in the future, providing a more powerful guarantee for people's travel safety.
